HS Series Standard Stepper Motors

Highlights:

• 2 phase or 3 phase
• NEMA 14 to 42
• Holding toque of 0.07 Nm to 28 N.m (9.9 – 3,965 oz-in)
• High precision
• Smooth movement
• Low motor heating
• Low movement noise

Leadshine offers 2 phase 1.8° and 3 phase 1.2° hybrid stepper motors made of high quality materials. Their frame sizes are available in NEMA 14, 16, 17, 23, 34, and 42 with holding torque of 0.07 to 28 Nm (9.9 – 3,965 oz-in). At very high precision and no obvious resonance areas, Leadshine 2 phase stepper motors can move quietly & smoothly, and generate low motor heating and noise.

The Leadshine HS series has been on the market for over 10 years. Although many of the models in this series are still widely implemented, over the time most of those models will be phased out. Therefore, for new applications we would suggest you to look into our CM series stepper motors
