Product Descriptions :
Features:
- High accuracy MCU control is employed to synchronously detect whether the 3 tool channels can be used independently and synchronously without matual interference.
- Built-in vacuum generator.
- Super power. The whole machine can provide a maximum of 900W power output.
- Stand-alone machine can carry out multiple desoldering tasks simultaneously.
- Large screen graphics display screen which can display all kinds of parameter data and messages graphically.
- The contents can be presented abundantly
- Automatically identify all kinds of welding tools and load corresponding parameters.
- The software can adjust the temperature automatically which is more accurate and convenient.
- Fault display and alarm functions available.
- Functions such as standby,buzzer ringing,temperature lock and factory data reset available.
- Support communication interface.It can access to a computor,and complete various settings following the specified program.
- Vacuum desoldering pen is added to facilitate dismantle the desoldering components.
Technical Specifications :
| Input Voltage | AC 100V/110V/120V // 220V/230V/240V 50/60Hz (Optional) | |||
| Total Power | 900W(MAX) | |||
| Accessory Tool Name | Hot Air Station | Soldering Station | Desoldering Station | Electronic Tweezers |
| Power | Heating component 550W,air pump 25W | 130W | Heating component 150W,vacuum pump:15W | 100W |
| Output voltage | The same with the input power | 24VDC | 24VDC | 12VDC |
| Temperature range | 150~500℃ | 150~500℃ | 150~500℃ | 150~500℃ |
| Standby time | NA | 1-120 minutes | 1-120 minutes | 1-120 minutes |
| Air flow grades | 23L/min | NA | NA | NA |
| Noise | <52dB(A) | NA | NA | NA |
| Temperature adjusting range | -50~+50℃/-90~+90℉ | |||
| Lock setting | Available | |||
| Temperature stability | ±5℃ | ±2℃ | ±2℃ | ±2℃ |
| Tip to ground impedance | <2Ω | |||
| Tip to ground voltage | <2mV | |||
