Product Descriptions :
- 4 Bits digital display, Precision reaches to 10mV, 1mA.
- 5 Sets of data storage functions to quickly obtain frequently-used data, easy to use.
- Adopt digital encoder, have higher precision, better stability and longer life than traditional potentiometer
- With OVP、OCP、OHP functions, OVP/OCP can be set according user’s requirement.
Technical Specifications :
| Specifications： | Voltage： | Current： |
|---|---|---|
| Model：APS3005Dm+ | Load regulation：<0.3{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50}+5mV | Load regulation：<0.2{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50}+3mA |
| Input voltage：220V±10{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50},50Hz | Line regulation：<0.3{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50}+5mV | Line regulation：<0.2{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50}+3mA |
| Rated output voltage：0~33V | Setting resolution：10mV | Setting resolution：1mA |
| Rated output current：0~5.5A | Setting accuracy：≤0.5{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50}+5mV | Setting accuracy：≤0.2{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50}+3mA |
| Protection functions：OVP/OCP/OHP | Backward read resolution：10mV | Backward read resolution：1mA |
| Operation condition：Temperature 0℃ ~40 ℃ relative humidity＜ 80{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50} | Backward read precision：≤0.2{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50}+2 digits | Backward read precision：≤0.2{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50}+2 digits |
| Storage condition：Temperature -15℃~70 ℃ relative humidity＜80{9a7b30434222e1c8bb37c89df41d0f3b40855e2238a80be0bf7298efc3fb7f50} | Ripple：10mVrms | Ripple：2mArms |
| Heating-dissipating method：Air cooling | ||
| Weight：2.6KG/PCS | ||
| Size: (WxHxD)111x170x250m |
