- Adopt imported brand temperature control system , the quality is reliable and stable , the heating element and the temperature sensor are all imported brands , the temperature control can be accurate to plus or minus 0.1 degrees , so that the hot melt adhesive is evenly heated, does not change color, does not carbonize, does not change the original Hot melt adhesives have good chemical and physical properties.
- Progressive preheating melting tank design , first melt first , inner coating imported DuPont Teflon anti- adhesive coating , low energy consumption , reduce glue carbonization phenomenon , can maintain the best glue quality.
- With temperature over-temperature alarm power-off protection function, the over-temperature value of 1-50 degrees can be freely adjusted. When the actual temperature exceeds the set value, the total power supply of the machine is automatically turned off. Taiwan’s Shan State Motor and Taian Inverter are used, and electrical components are imported joint venture brands.
- Double-layer 100 mesh filter screen reduces the phenomenon of nozzle clogging. The new type of guiding reflow device makes the rubber pressure adjustment more precise and stable . The melting cylinder is welded with the latest precision technology and is guaranteed for ten years.
- Adopt high-precision imported gear pump, the pressure output of the glue is stable, and the pump body is manufactured by heat treatment of imported high-speed steel, which prolongs the service life of the pump and free warranty for three years, which greatly reduces the maintenance cost of the customer and improves the production efficiency.
- Motor protection function, when the actual temperature of the glue tank does not reach the set temperature value, the (motor) motor does not work, it plays a protective role, prolongs the service life of the equipment and avoids the economic loss brought by the employee’s illegal operation.
- Adopting the circuit design conforming to the EU standard, with automatic leakage protection function of leakage, making the whole equipment safer to use, voltage detection, voltage overvoltage and current overcurrent protection function to prevent damage to the equipment system due to sudden high voltage. . With current and voltage protection and other functions.
Applications: refrigerator sealing and filling, air filter industry, non-woven industry, carton carton sealing and packaging industry, with the use of automation equipment and other related industries.
|Storage capacity||5 kg|
|Melt speed||5 kg / h|
|Use viscosity||2,000-20,000 CPS|
|Operating temperature||≤250 °C|
|Plastic barrel size||550mmx450mmx500mm|
|Number of hoses that can be connected||2 Tiao|
|Temperature sensing method||K type / PT100 / ni120 (three options)|
|program||Can go round, curved, curved, straight, polyline, point, square|
|Travel range X/Y/Z (mm)||300/300/100|
|Movement speed (mm/sec)||0–500|
|Decomposition ability||0.01 mm/Axis|
|Repeatability||± 0.02 mm / Axis|
|Program recording mode||At least 100 , 5000 points per group|
|Display method||LCD teach pendant|
|Motor system||Japanese micro stepping precision motor|
|transfer method||Timing belt / screw|
|Motion tween function||3 axis ( any route in 3D space )|
|Input power||Full voltage AC110V ~ 220V|
|External control interface||RS232|
|Body weight (kg)||48 KG|
